Instrumentation equipment in the oil and gas industry plays a vital
role in monitoring, controlling, and ensuring the safety and
efficiency of industrial processes. This section provides a concise
overview of common types, standards, and connection methods for
such equipment.
The type refers to a specific category of instrumentation
designed to measure or control a particular parameter.
Instrumentation is available in a variety of sizes to meet specific system requirements. Size can refer to the sensor diameter, probe length, or flange/connection diameter. Selecting the appropriate size is essential for ensuring compatibility with the design and system requirements.
Each instrumentation device has a specific pressure rating it can safely handle. This value is crucial to avoid damage due to excessive pressure. The working pressure must be compatible with the maximum operational pressure of the system.
The materials used in instrumentation are critical to ensuring durability and resistance to corrosion, especially in harsh environments. Instruments can be made from materials such as stainless steel, aluminum, and specialized alloys
| Category | Instrument Name | Description (مشخصات فنی مختصر) |
|---|---|---|
| Pressure | Pressure Transmitters | سنجش فشار خروجی آنالوگ/دیجیتالی تا 600 بار |
| Differential Pressure Transmitters | سنجش اختلاف فشار، مناسب برای فیلتر و فلومتر | |
| Pressure Gauge | نمایش فشار مکانیکی اعداد به صورت دورانی | |
| Pressure Switches | سوئیچ فشار با نقطه قطع/وصل قابل تنظیم | |
| Pressure Indicator | نمایشگر فشار دیجیتال یا آنالوگ | |
| Temperature | Bimetal Thermometers | دماسنج صنعتی آنالوگ، بینیاز از برق |
| RTD (Resistance Temp. Detector) | سنسور دمای دقیق مقاومتی PT100/Pt1000 | |
| Temperature Transmitters | مبدل سیگنال دما به جریان یا ولتاژ | |
| Thermocouples | سنسور دمای نوع J,K,T و ... | |
| Temperature Transmitter | مبدل سیگنال دما به جریان یا ولتاژ | |
| Flow | Magnetic Flowmeter | دبیسنج مغناطیسی برای سیالات رسانا |
| Vortex Flow Meter | دبیسنج مناسب بخار و گاز براساس ایجاد گردابه | |
| Turbine Flowmeter | اندازهگیری دبی حجمی با پره چرخان | |
| Variable Area Flowmeter (Rotameter) | دبیسنج شناوری ساده، مناسب برای مایعات و گازها | |
| Level | Ultrasonic Level Transmitter | سنجش سطح بدون تماس با امواج فراصوت |
| Radar Level Transmitter | سطحسنج راداری با دقت بالا | |
| Vibration/Tilt Level Switch | تشخیص سطح جامدات با سنسور لرزش یا کجشدن | |
| Limit Switches | سوئیچ مکانیکی یا مغناطیسی | |
| Electrode Type Level Switch | سطحسنج الکتریکی براساس هدایت جریان | |
| Nuclear Radiation Level Switch | سطحسنج با ایزوتوپ رادیواکتیو | |
| Float Type Level Instrument | سنجش سطح با شناور مکانیکی | |
| Ultrasonic Level Transmitter | سنجش سطح بدون تماس با امواج فراصوت | |
| Radar Type Level Transmitters | سطحسنج راداری با دقت بالا | |
| Flow Accessories | Orifice Plates and Flanges | صفحات دبیسنج با فلنج مربوطه |
| Restriction Orifices | صفحات محدودکننده جریان | |
| Safety & Control | Pull Rope Emergency Switches | سوئیچ اضطراری برای نقالهها |
| Skew Switches | سنسور انحراف تسمه نقاله | |
| Speed Switches | سنجش و کنترل سرعت دوار |
